194 B2232-23 Mirror Fold/Unfold Switch- Signal Stuck Low
700
N
195 U1016-12
Control Module Output Power 1- Circuit Short to
Battery
705
N
196 U1016-14
Control Module Output Power 1- Circuit Short to
Ground/ Open
709
N
197 U1017-12
Control Module Output Power 2- Circuit Short to
Battery
713 N
198 U1017-14
Control Module Output Power 2- Circuit Short to
Ground/ Open
717
N
199 B2218 - 11
Headlamp Auto On Enable Switch - Circuit Short
to Ground
721
N
200 B2218 - 12
Headlamp Auto On Enable Switch - Circuit Short
to Battery
725
N
201 B2232 - 11
Mirror Fold/Unfold Switch - Circuit Short to
Ground
729 N
202 B2232 - 12
Mirror Fold/Unfold Switch - Circuit Short to
Battery
732
N
203 B2230 - 11
Master Light Switch Fail Safe Signal - Circuit
Short to Ground
735
N
204 B2230 - 12
Master Light Switch Fail Safe Signal - Circuit
Short to Battery
739
N
205 B223C - 11
Rear Wiper Fixed Interval Signal - Circuit Short to
Ground
743 N
206 B223C - 12
Rear Wiper Fixed Interval Signal - Circuit Short to
Battery
747
N
207 B1F08 - 11
Illumination Level Switch - Circuit Short to
Ground or Open
751
N
208 B1F08 - 12 Illumination Level Switch - Circuit Short to Battery
755
N
209 B160B - 12
Door Unlock control driver Relay/ Tailgate Unlock
Control Relay - Circuit Short to Battery
759
N
210 B1F04 - 11 Front Courtesy Light - Circuit Short to Ground
763
N
211 B161A - 11 Internal Unlock Switch - circuit short to ground
767
Y1
212 B161A - 12 Internal Unlock Switch - circuit short to battery
768
Y1
