Vehicle Platform: OSPREY
ECU Name: Hella Body Control Module (BCM) DTC
Troubleshooting Data
Version: 1.4
Date: 15 May 2018
Author: Body CoC
Page: 851 of 855
Copyright © TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
176 B1619 - 11 Internal Lock Switch - Circuit Short to Ground
660
N
177 B1619 - 12 Internal Lock Switch - Circuit Short to Battery
663
N
178 B1619 - 23 Internal Lock Switch - Signal stuck Low
666
N
179 U1013 – 11 WakeUp Signal – Circuit Short to Ground
669
N
180 U1013 – 12 WakeUp Signal – Circuit Short to Battery
673
N
181 U0100-87
Lost Communication with ECM Missing
Message failure
677
Y
182 U0101-87
Lost Communication with TCM TCM Missing
Message Failure
678
Y
183 U1309-87 Braking System ABS Missing Message Failure
679
Y
184 U0164-87
Lost Communication with HVAC Control Module
Missing Message Failure
680 Y
185 U0151-87
Lost Communication with Restraints Control
Module (SRS) – Missing Message Failure
681
Y
186 U0155-87
Lost Communication with instrument Panel
Cluster IPC Missing Message Failure
682 Y
187 U0167-87
Lost Communication with Vehicle Immobilizer
Control Module VICM Missing Message Failure
683
Y
188 B160B-14
Door unlock control driver relay/tailgate unlock
control relay – circuit short to ground or open
684 N
189 U1310-87
Lost Communication With Trailer (TR) Control
Module - missing message
685
Y
190 U0254-87
Lost Communication With Remote Start Module -
missing message
686
Y
191 B2203-11
Combined External Mirror Folding Signal- Circuit
Short to Ground
687
N
192 B2203-15
Combined External Mirror Folding Signal- Circuit
Short to Battery/ Open
692
Y4
193 B225B-09 Master Light Switch Failure- Component Failures
696
N
