HARRIER BOOK 2

Vehicle Platform: OSPREY

ECU Name: Hella Body Control Module (BCM) DTC

Troubleshooting Data

Version: 1.4

Date: 15 May 2018

Author: Body CoC

Page: 635 of 855

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

DTC’s confirmation:-

After rectification, ensure the following points by using TML diagnostic tool before handing over to customer.

a) Switch IGN ON and Position lamp ON.

b) Change the Cockpit illumination level setting through rotary switch and ensure that illumination level

changes as per the rotary switch settings.

c) Read DTC and ensure that B1F07 – 15 shall not be logged.

Connector View & Information: -

Please refer respective BCM Drawing for BCM connector PIN details.

Inspection Method: -
