U100F - 12: Ignition Power mode Input - Circuit Short to Battery
Overview:
ISO Code (DTC Code)
U100F - 12
Customer Symptom
Active power mode may operate when in Accessory or
battery-only power mode
Fault Effects (On Vehicle)
1. Active power mode may operate when in
Accessory or battery-only power mode
2. Battery Drain
Lamp Status (If Any)
NA
Fault Detection Condition
This fault will be logged after the input switch test
routine execution. User has to operate the switch
manually during routine. If short to battery fault is
detected for ignition power mode input switch then this
DTC code will be returned with the Routine results.
Normal Operating Condition
There should not be any fault returned by routine.
Probable Trouble Area
1. BCM connector wired wrong
2. Cockpit wiring harness short to battery
3. switch damaged
4. Ignition switch failure
Healing Condition
1. Ignition OFF
ON
2. Clear DTC Command
Component Details:
Ignition power mode input switch is part of Ignition switch and interfaced to the BCM. If the Ignition
power mode input switch is activated and all functionality will work properly and if user put the ignition
switch to ignition power mode input position, all functionality will work.
Ignition power mode input switch is active high.
Preliminary Checks:
1. Check Battery Voltage (9V-16V)
2. Check ECU pins for oxidation, bending & damage.
Trouble Shooting:-
