B130D - 12: Right Rear Door Ajar Switch - Circuit short to Battery or Open Circuit

Overview:

ISO Code

B130D - 12

Customer Symptom

1. Interior Roof lamp in Auto mode selection

doesn’t operate when Rear Right door is

opened.

2. The IC shows Rear Right door as closed status,

even if the Rear Right door Rear Right door is

opened as presumed by the customer.

3. The Mis-lock sound does not occurs on RKE

lock command.

4. The vehicle will get lock on RKE lock command.

Fault Effects (On Vehicle)

Interior Roof lamp in Auto mode selection does not

operate when Rear Right door is opened.

Lamp Status (If Any)

1. Roof lamp in Auto mode selection is OFF.

2. IC shows Rear Right door closed status always

Fault Detection Condition

This fault will be logged after the input switch test

routine execution. User has to operate the switch

manually during routine. If short to battery or open

circuit fault is detected for Right Rear Door Ajar Switch,

then this DTC code will be returned with the routine

results.

Normal Operating Condition

There should not be any fault returned by routine

Probable Trouble Area

1. BCM connector Fault

2. Right side wiring harness Short to battery or

open circuit

3. Right Rear Door Ajar Switch is damaged or stuck

or faulty

4. BCM ECU fault

Healing Condition

1. Ignition OFF



2. Clear DTC Command

Component Details:

Right Rear Door Switch, BCM connector

Functionality:

If the Right Rear Door Switch is short to Battery or Open Circuit, then the Right Rear Door state is in

closed state.

If the Right Rear Door is closed, then BCM shall receive the feedback of Right Rear Door as closed

status.

Preliminary Checks:

1. Check Battery Voltage (12.5 V & above)

2. Check ECU pins for oxidation, bending & damage.
