Vehicle Platform: Tiago,Tigor & Osprey
ECU Name: Hella Body Control Module (BCM)
DTC Troubleshooting Data
Version: 2.0
Date: 22-10-2018
Author: Parag K
Page: 730 of 737
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
17
U1009 - 16
Control Module Input Power 2 circuit voltage below
threshold
68
N
18
U1009 - 17
Control Module Input Power 2 circuit voltage above
threshold
72
N
19
U100A - 16
Control Module Input Power 3 circuit voltage below
threshold
76
N
20
U100A - 17
Control Module Input Power 3 circuit voltage above
threshold
80
N
21
B2236 - 12
Position Lamp Switch Circuit Short to Battery
84
N
22
B2236- 11
Position Lamp Switch Circuit short to Ground
89
N
23
C0040 – 11
Brake Pedal Switch Circuit short to Ground
94
N
24
C0040 – 12
Brake Pedal Switch Circuit short to Battery
99
N
25
B221A– 12
Headlamp On Signal – circuit short to battery
103
N
26
B221A – 11
Headlamp On Signal – Short to Ground
108
N
27
B225A– 14
Front Fog Lamp Relay– Short to Ground or Open
113
N
28
B225A– 12
Front Fog Lamp Relay – Short to Battery
118
N
29
B222C– 11
Low Beam Relay– Short to Ground
123
N
30
B222C – 12
Low Beam Relay – Short to Battery
128
N
31
B2204– 11
Combined High Beam Circuit – Short to Ground
133
N
32
B2204 – 12
Combined High Beam – Short to Battery
138
N
33
B2224– 11
Left Position Lamps– Short to Ground
143
N
34
B2224 – 15
Left Position Lamps – Short to Battery or Open Circuit
148
N
35
B2247– 11
Right Position Lamps– Short to Ground
153
N
36
B2247– 15
Right Position Lamps – Short to Battery or Open Circuit
158
N
37
B221F – 11
Left Front Fog Lamp Circuit Short to Ground
163
N
