Vehicle Platform: Tiago,Tigor & Osprey
ECU Name: Hella Body Control Module (BCM)
DTC Troubleshooting Data
Version: 2.0
Date: 22-10-2018
Author: Parag K
Page: 736 of 737
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
143
B2215- 1C
Front Wiper Variable Speed Switch voltage out of range
655
N
144
U0100-87
Lost Communication with ECM Missing Message failure
659
Y
145
U0151-87
Lost Communication with Restraints Control Module
(SRS) – Missing Message Failure
660
Y
146
U0155-87
Lost Communication with instrument Panel Cluster IPC
Missing Message Failure
661
Y
147
U0167-87
Lost Communication with Vehicle Immobilizer Control
Module VICM Missing Message Failure
662
Y
148
B2267-09
B2267 – 09: Emergency HW Path Failure (Brake Lamps /
Position Lamps / Low Beam output) – Component
Failures
663
N
149
U0420-81
Invalid Data Received From Power Steering Control
Module
681
Y
150
B1922-11
Proximity Sensor Rear RH input-Circuit short to Ground
683
N
151
B1922-12
Proximity Sensor Rear RH input-Circuit short to Battery
687
N
152
B1922-13
Proximity Sensor Rear RH input-Circuit open
691
N
153
U130B-08
Lost communication with HU-Bus Signal/Message
failures
694
N
154
U130B-87
Lost communication with HU-missing message
697
N
155
U131E-08
Lost Communication with Rear PDC
699
N
156
B1929-96
Proximity sensor Rear RH failure
702
N
