B2213 - 97: Front Wiper Park Position Signal - Component or system operation obstructed or blocked
ISO Code
B2213 - 97
Customer Symptom
Front and rear wash/wipe may not function correctly
Fault Effects (On Vehicle)
Front and rear wash/wipe may not function correctly
Lamp Status (If Any)
NA
Fault Detection Condition
This fault will be logged when user operates the front wiper
motor with front wiper is out of park for more than
preconfigured delay time due to failure in park input. If out of
park fault is detected for front wiper park position signal for
more than defined delay then this DTC code will be returned
with the results.
Normal Operating Condition
There should not be any fault returned by routine
Probable Trouble Area
1. BCM connector FaultC
2. Cockpit harness Short to battery or open
circuit
3. BCM ECU fault
Healing Condition
1. Ignition OFF
ON
2. Clear DTC Command
Component Details:
Front wiper Park Position Signal part of front wiper motor and interfaced to the BCM as a feedback input. If the
IGN is on and if user put the combi switch to front wiper on position, front wiper park position signal gives a
feedback to BCM about the in park and out of park of the front wiper.
Preliminary Checks:
Check Battery Voltage (12.5 V & above)
Check ECU pins for oxidation, bending & damage.
Trouble Shooting:-
