Step 4: Below Routine to be executed
“DPF 1 - Replacement of ECU and Old ECU is not communicating (Set EEPROM values for PFlt_CoRgn
Exchange of ECU) ($ 02 06)”
Routine Execution Detail:
Refer Section 4.3.1 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224
A1724_5June2017_V0.2’ document
Step 5: Below Routine to be executed
“TVA DC Motor Test”
Routine Execution Detail:
Refer Section 4.11 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224
A1724_5June2017_V0.2’ document
Step 6: Below Routine to be executed
“EGR high pressure DC Motor Test”
Routine Execution Detail:
Refer Section 4.7 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224
A1724_5June2017_V0.2’ document
Step 7: Below Routine to be executed
“DPF Service Regeneration”
Routine Execution Detail:
Refer Section 4.3.2.2 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224
A1724_5June2017_V0.2’ document
Step 8: Below Routine to be executed
“VGT DC Motor Test”
Routine Execution Detail:
Refer Section 4.12 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224
A1724_5June2017_V0.2’ document
Step 9: Below Routine to be executed
“VGT DC Motor Test”
Routine Execution Detail:
Refer Section 4.12 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224
A1724_5June2017_V0.2’ document
