$ 27 04 XX XX XX XX (XX is the key calculated from the seed received through 27 02
command)
Command:
$ 2E 38 33 YY
(for writing the data back into New ECM)
$ 2E 38 43 YY
(for writing the data back into New ECM)
Where
YY
is data read from Old ECM
Step 4:
Proxi realignment / Variant COnfiguration to be done:
Perform Variant Configuration Reset:
Refer Section 4.21 – Variant Configuration Reset in ‘TML_PT_Q5_Routine Procedures_EMS
Requirement_2921 02 224 A1724_5June2017_V0.2’ document for routine procedure detail.
Perform the Variant Configuration after entering extended Diagnostic Session and Taking Security Access:
Pick the 6 byte variant configuration value from PLM for specific vehicle variant and save in Tester.
Command:
$ 10 03
Command:
$ 27 03
$ 27 04 XX XX XX XX (XX is the key calculated from the seed received through 27 02
command)
Command:
$ 2E FE AA YY
Where YY is 6 Byte value
[
Note:
Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is all procedures are completed
and steps are performed in EMS ECU.]
