P1567-24: When Cruise Active, Cruise + Switch / button is pressed for pro-longed acceleration (Greater than

Calibrate-able threshold (Def. 10 Sec))

Overview:

DTC Description (User Friendly)

When Cruise Active, Cruise + Switch / button is pressed for

pro-longed acceleration (Greater than Calibrate-able

threshold (Def. 10 Sec))

ECU Pin Number

K029 – Input analog signal to EMS

K033 – Ground signal to cruise button from EMS ECU

Customer Symptom

MIL OFF, CEL OFF

Fault Effects (On Vehicle)

Lamp Status (If Any)

Fault Detection Condition (Root cause)

If press cruise + switch for pro longed acceleration (greater

then threshold148). The fault is set if any shut off selected by

536870912 is set.

Normal Operating Condition

Proper wire harness connection between Cruise Cncl button

and EMS ECU.

Probable Trouble Area

Wire harness connection between Cruise Cncl button and

EMS ECU.

Healing Condition

Rectify the error Clear through diagnostic tool.

Ignition OFF & ON

Component Details:

Cruise control is a system that automatically controls the

speed

of a

motor vehicle.

The system is a

servomechanism

that

takes over the

throttle o

f the car to maintain a steady speed as set by the driver.

Preliminary Checks:

1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned in above

Table. If yes, go ahead with next steps. If not, check for other DTC’s presence.

2. Check whether other customers report similar complaints earlier. If yes, perform the preliminary checks with

respect to earlier issue closure.

3. Check for wire harness connection between EMS and Cruise Cncl button.

4. Check for any back out of pins at EMS ECU connector.

5. Check for any damage of pins at EMS ECU connector.

Trouble Shooting:

Step Checks

IF YES

IF NO
