TML HARRIER Infotainment DTC Troubleshooting guide
Version: 0.2 Draft
Date: 31-Jul-18
Author:
Vijaya Bhaskar
B/Pritam Bansod
Page: 112 of 113
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
13
B1C20-13
Steering Wheel Control Input Signal - circuit open
43
No
14
B1C04-13
GPS Signal - circuit open
48
No
15
B1C4B-13
Infotainment Display LVDS connector - circuit open
53
No
16
B1C52 -13
IC Display-LVDS connector - circuit open
No
17
B1C4D-08
Button Panel LIN - Bus Signal / Message Failures
58
No
18
U0028-13
Vehicle Communication Bus A - open circuit
64
No
19
U0028-88
Vehicle Communication Bus A - Bus off
66
No
20
U0155-08
Lost Communication With Instrument Panel Cluster
(IPC) Control Module - Bus Signal / Message Failure
68
Yes
21
U0140-08
Lost Communication with Body Control Module -
Bus Signal / Message Failures
73
Yes
22
U0159-08
Lost Communication with Parking Assist Control
Module "A" - Bus Signal / Message Failures
80
Yes
23
U0164-08
Lost Communication with HVAC Control Module -
Bus Signal / Message Failures
85
Yes
24
B1C4A - 56
BCM pairing detection - Invalid / incomplete
configuration
