Appendix
Sr.
TML Displayed
DTC Code
DTC Description
Page No.
Display Status
(Mask Status)
1
B1C01-13
AM/FM Antenna Signal Input Open Circuit
8
No
2
B1C33-2A
Hard Switch (Push Button/Rotary Knobs) - signal
stuck in range
13
No
3
B1C0E-13
Microphone Signal Input - circuit open
17
No
4
B1C0A-13
Left Rear Speaker Assembly Output Power / Left
Rear Speaker Assembly Input Signal 1 - circuit open
22
No
5
B1C0B-13
Right Rear Speaker Assembly Output Power / Right
Rear Speaker Assembly Input Signal 1 - circuit open
26
No
6
B1C08-13
Left Front Speaker Assembly Output Power / Left
Front Speaker Assembly Input Signal 1 - circuit open
31
No
7
B1C09-13
Right Front Speaker Assembly Output Power / Right
Front Speaker Assembly Input Signal 1 - circuit open
35
No
8
B1C4E-13
Right Rear Tweeter Assembly Output Power / Right
Rear Tweeter Assembly Input Signal - circuit open
No
9
B1C4F-13
Right Front Tweeter Assembly Output Power / Right
Front Tweeter Assembly Input Signal - circuit open
No
10
B1C50-13
Left Front Tweeter Assembly Output Power / Left
Front Tweeter Assembly Input Signal - circuit open
No
11
B1C51-13
Left Rear Tweeter Assembly Output Power / Left
Front Tweeter Assembly Input Signal - circuit open
No
12
B1C20-2A
Steering Wheel control Signal Input – Stuck in Range
39
No
