TML HARRIER Infotainment DTC Troubleshooting guide
Version: 0.2 Draft
Date: 31-Jul-18
Author:
Vijaya Bhaskar
B/Pritam Bansod
Page: 87 of 113
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Silver Box ECU side connector diagram
Silver Box
ECU Pin assignment:-
Connector
No.
Pin No.
Pin Name
Description
C1
2
CAN_H
CAN High
C1
5
CAN_L
CAN Low
A
7
Vbatt
Supply Voltage Battery
A
5
IGN
IGN
A
8
GND
Power GND
TBA
