KRYOTEC ENGINE
78
I. ALTERNATOR REMOVAL AND REFITMENT
REMOVAL
1. Remove the underbody engine guard.
2. Remove the auxiliary belt.
(For removal
procedure refer ac compressor and alternator
belt replacement).
3. Remove fuel filter.
(For removal procedure refer
fuel filter replacement).
4. Remove the electrical connections of the
alternator.
5. Loosen and remove the mounting bolts on the
alternator support brackets.
6. Take out the alternator.
FITMENT
For fitment follow removal procedure in reverse.
J. COMPRESSOR
REMOVAL
AND
REFITMENT
REMOVAL
1. Remove underbody engine guard.
2. Recover refrigerant from the vehicle.
3. Remove the auxiliary belt.
(For removal
procedure refer ac compressor and alternator
belt replacement).
4. Disconnect the electrical connection of the
compressor.
5. Disconnect the suction and discharge hose of
the compressor.
