KRYOTEC ENGINE
73
The specified resistance values and calibration details of the tank unit fuel gauge are given below:
NOTE
:
Fuel Display will show summarized value of both float position.
READING
FUEL MODULE LEVEL SENSOR
SUCTION UNIT LEVEL SENSOR
FLOAT
HEIGHT
(mm)
FUEL
LEVEL
(mm)
FUEL
VOLUME
(Ltrs.)
RESIST-
ANCE
(Ohm)
FLOAT
HEIGHT
(mm)
FUEL
LEVEL
(mm)
FUEL
VOLUME
(Ltrs.)
RESIST-
ANCE
(Ohm)
END
STOP
FULL
204 ± 2
212.0
52.2
40
+1
204.1 ± 2 212.0
52.2
66
+1.2
-0.8
-1.0
FULL
195 ± 2
203.2
49.4
44
+1
195.3 ± 2 203.2
49.4
68
+1.2
-0.8
-1.0
3/4
176 ± 2
184.4
20.2
56
+1.1
149.5 ± 2 157.3
19.1
88
+1.4
-0.9
-1.2
1/4
140 ± 2
147.6
15.3
78
+1.3
65.2 ± 2
73.1
7.3
126
+1.8
-1.1
-1.6
LOW
FUEL
82 ± 2
90.2
8.3
110
+1.6
14.4 ± 2
22.1
1.7
150
+2.0
-1.4
-1.8
EMPTY
35 ± 2
43.0
3.3
138
+1.9
-1.7
