KRYOTEC ENGINE
32
v. DRAINING WATER FROM FUEL FILTER
1. Stop the engine allow the pressure to
stabilize.
2. Disconnect the electrical connection of the
fuel filter and also disconnect one of the fuel
lines either inlet or outlet.
3. Loosen the water drain port nipple. Connect
suitable tool to the water drain port and drain
water.
4. Reconnect the fuel line and electrical
connection that was disconnected.
NOTE
Drain the water from the fuel filter during every
service.
v
i
. AC COMPRESSOR, ALTERNATOR BELT
REPLACEMENT
REMOVAL
1. Lift the vehicle and remove the RH side front
wheel.
(For procedure refer wheel section).
2. Remove the RH front wheel arch.
(For
procedure refer Body section).
3. Loosen the belt tensioner by rotating bolt in
anticlockwise direction and lock using special
tool
(5412 5890 0605)
.
