KRYOTEC ENGINE
31
FUEL FILTER REPLACEMENT
WARNING
If diesel leakage is detected, do not start the
vehicle or allow an open flame or spark near the
vehicle. Have the fuel leak repaired immediately.
The fuel system is under pressure. Relieve fuel
system pressure before replacing the filter.
DESCRIPTION
The fuel filter is mounted inside the engine bay
next to coolant auxiliary tank. It is mounted on the
support bracket. Replace the fuel filter as per
service schedule. When the vehicle is operated in
adverse conditions or where fuel quality is
questionable, more frequent replacement may be
necessary.
REMOVAL
1. Relieve fuel system pressure by removing the
power supply to the system fuel pump and
cranking the engine.
2. Disconnect the negative (-) battery cable.
3. Remove the fuel line connections (Quick fit
Connectors) to the fuel filter.
4. Remove two mounting fasteners and take it
out from mounting bracket.
INSTALLATION
1. Follow the removal procedure in reverse.
2. Start the engine and inspect the connections
for leaks. Stop the engine immediately and
repair if any leaks.
