KRYOTEC ENGINE
30
iii. AIR FILTER ELEMENT REPLACEMENT
DESCRIPTION
Proper maintenance of the air filter is essential
for vehicle performance and fuel economy. The
air filter element removes foreign material such
as dust, dirt, and other material from the
intake air, thereby preventing the engine from
damage due to contaminated air.
Inspect and replace the air filter element.
Replace the air filter element as per service
schedule.
REMOVAL
1. Park the vehicle on a level surface, engage
the parking brake, and raise the hood.
2. Disconnect electrical connection to MAF
sensor.
3. Unscrew the top six mounting bolts of air filter
assembly.
4. Move aside the top cover of air filter along
with air duct and remove the air filter element.
INSPECTION
1. Hold the air filter element up to a light
source. Light should be visible through the
element. There should be no holes or tears
in the element.
2. Replace the filter element if torn or light is
not visible through the filter.
INSTALLATION
Follow the removal procedure in reverse
!! WARNING
No cleaning of air filter element during service
to be made as this may damage air filter
element, pre filter and further engine.
