361 / 948
BRAKES
31
11.After the bleeding sequence is completed
remove the bleed tube and place the dust cap
on the bleed screw.
12.Ensure that the bleed screw is tightened to the
recommended torque.
NOTE
After the bleeding is done check for any leaks in
the bleed screw by applying the brake pedal hard.
C. CALIPER PAD REPLACEMENT
NOTE
Caliper pad replacement for front and rear caliper
can be done in similar manner, therefore follow
the same procedure of caliper pad replacement
for removal of rear caliper pads after removal of
rear tyres.
1. Keep the gear shifter lever in neutral position.
2. Apply the parking brake.
3. Jack the vehicle and remove the front wheel.
4. Loosen and remove the bottom sliding pin bolt.
NOTE
Before removing the sliding pin bolt, ensure that
the pedal is fully depressed i.e. caliper is fully
returned at zero condition.
5. Swing the caliper up, hold with one hand and
then remove the pads one after the other.
