ZEST/BOLT

ELECTRICAL

TELL TALES

COLOR

INDICATOR

REMARKS

Diesel Pre-

Heat/Glow

pluge indicator

Amber

Illuminates momentarily when ignition is switched ‘ON’ to

indicate that the glow plugs are active. It will continuously

illuminate when engine is getting preheated. Start the

engine only after the indicator goes off.

Turn Signal

Green

Indicates direction indicated by the turn signal. Blinks

along with buzzer while operating left/right turn indicator

only when ignition is switched ‘ON’.

High Beam

Blue

Illuminates when the high beam headbulbs are switched

ON or flashed.

Front Fog

Green

Illuminates when front fog bulbs are switched ‘ON’.

Rear Fog

Amber

Illuminates when rear fog bulbs are switched ‘ON’.

Low Oil

Pressure

Red

1. Illuminates momentarily when ignition is switched ‘ON’.

2. Illuminates continuously if engine oil level is less than a

pre-defined minimum level. Stop the vehicle as soon as

safety permits and switch off the engine. Check engine oil

level and top-up if required. Contact qualified TATA

MOTORS assistance before starting the engine.

Battery

charging/

engine warning

Red

Illuminates momentarily when ignition is switched ‘ON’

once

is cranked, it goes OFF.

It will continuously illuminate when there is malfunction of

charging system. Contact TATA MOTORS Authorized

Service Centre

Park Brake

cum Low

Brake

Fluid/ABS or

EBD

Malfunction.

Red

1. Illuminates momentarily when ignition is switched ‘ON’

once engine is cranked, it goes OFF.

2. When brake fluid level is low.

3. When park brake is applied and goes OFF when it is

released

4. When ABS/EBD system has a fault.

Seat belt

warning

Red

Indicates that seat belt is not fastened when ignition is

‘ON’. It will flash along with buzzer for 6 secs when ignition

is switched ‘ON’ and seat belt is not fastened. It will

continue to flash until the car exceeds a speed of 20

kmph. After that, it will remain continuously ON along with

a buzzer that will be audible for approx. for100 secs. Then

buzzer goes OFF but the indicator continues to remain ON

until seat belts are fastened.
