1132 / 1232
ELECTRICAL
98
6
Clock
Indicates current time in 12 Hrs mode.
Note: You can change the clock time using SET and
MODE buttons.
Whenever the battery terminals or related fuses are
is connected you must reset the clock time. This
feature is available when ignition switch is in ON
position.
7
Outside Ambient
Temperature
Displays outside ambient temperature in units °C or
°F.
This value may differ from the actual driving
distance available.
Resolution: 1 °C or °F
Note:
You can change the Temperature unit using SET
and MODE buttons.
°F is applicable for Export variant only.
The outside ambient temperature is not the actual
outside temperature when driving at low speed or
when stopped.
If display shows ‘- - ‘, take your car to a TATA
authorized service Centre.
8
Service reminder
Indicates the number of days or kilometers
remaining for next service at every ignition ON for
few seconds if service is due.
If service is overdue, DIS will display 0 km or 0 days
and spanner symbol will blink at every ignition ON
for few seconds.
DIS will indicate Spanner symbol as continuously
ON when service is overdue.
When Service reminder warning appears, take your
vehicle to Authorized TATA MOTORS service
station to reset Service reminder.
Note:
Take your vehicle to Authorized service station only
for servicing.
If service reminder warning is ignored and vehicle is
not serviced even if service overdue , service
reminder warning may not provide warning
9
Door Ajar
High End
Cluster:
Low End
Cluste
Indicates the door ajar warning.
For High end cluster all four doors and tailgate is
indicated separately for XT.
For XM and XMS, Co-Driver door indicates any of
the three doors i.e. Co-Diver door, Rear Right Door
and Rear left door.
For Low End Cluster, only Driver door warning will
be given.
