AIR CONDITIONING
45
2. AC COMPRESSOR ON / OFF BUTTON:
Press the AC compressor ON/OFF button to turn
the air conditioning ON or OFF. You will see AC
text on the display, when AC is ON.
3. ECON A.C.
During ECON AC operation, the system
automatically cuts off compressor at a higher
temperature than normal AC. The operation can be
used during mild weather conditions for better fuel
efficiency. Comfort level may be compromised
during this operation. By pressing ECON button
text will be displayed on display.
4. MAX DEFROST BUTTON :
A. This button directs the main airflow towards
windscreen for faster defrosting (It also
overrides any mode selection you may have
made.)
B. When you turn off the button, the system
returns to its former settings
CAUTION:
For your safety make sure you have a clear view
through all the windows before driving
.
5. REAR WINDOW DEFOGGER/DEMISTER
BUTTON:
A.
This button turns the rear window demister
ON or OFF. The system automatically
deactivates after 15 min of continuous
operation.
6. FRESH AIR / RECIRCULATION BUTTON:
A. When the recirculation Button or LED is
switched ‘ON’, air from the vehicle’s interior
is sent throughout the system.
B. When the recirculation button is switched off,
air is brought in from outside of the vehicle
(fresh mode). Whenever discomfort is felt,
switch to fresh air mode.
NOTICE:
1. The outside air intakes for the climate control
system are at the base of windscreen. Keep
this area clear from leaves and other debris.
2. The system should be used with recirculation
air mode for faster heat up and cool down,
however keeping the system in recirculation
mode, particularly with AC OFF, can cause
the windows fog up.
CAUTION:
It is recommended to run the vehicle in re
circulation mode to avoid clogging of air filter.
7. AIR DISTRIBUTION (MODE) BUTTON:
A
. In AUTO mode, the FATC system will
regulate the mode automatically. However
user override is possible with the use of
MODE button to select the desired airflow
mode. Each time you press the MODE button,
the display shows the mode selected.
Towards face
Towards face and leg
Towards leg
T
owards leg & windshield – demist or
defrost (Recommended for clearing
mist on windshield) - front air demist.
Towards
windshield
(defrost)
(Recommended for clearing heavy
fog or snow)
