BODY
14
6. Remove nacelle Assembly. (For removal refer
steering column removal process in steering
section.)
7. Remove combination switch assembly and
ignition switch assembly (For procedure refers
combination switch and ignition switch removal
process in Electrical section.)
8. Pull out instrument cluster hood.
9. Remove instrument cluster. (For procedure
refer instrument cluster removal process in
Electrical section.)
10.Pull out gap hider fitted on the dashboard sub
assembly.
11. Remove two steering column mounting nuts.
12. Pull out center air vent assembly and
Disconnect the electrical connection
13. Loosen and remove the four mounting
screws of air vent
