861 / 1265
BODY
20
4. Remove one screw at dashboard mid panel &
take out.
5. Remove three screw at LH side Air vent.
FITMENT
For fitment follow the reverse procedure of
removal.
1.4.6. FRONT BUMPER
REMOVAL
1. Open the bonnet.
2. Loosen and remove the mounting screws
along with the washers from the bottom side of
the bumper.
3. Remove two clip buttons from the bumper
which hold the head lamps.
4. Loosen and remove two mounting screws of
the outer liner from the inner side of wheel
arch. Follow the same procedure at the other
end also.
5. Pull out the front bumper from wheel arch end.
