14. Disconnect the electrical connection.
Remove music system (If applicable). (For
procedure refer music system removal process in
Electrical section).
15.Remove floor console assembly. (For
procedure refer floor console removal
process).
16.Remove PAB Assembly (If applicable). (For
procedure refer PAB removal process in SRS
section).
17. Pull out at end cover LH side
18. Remove one mounting screws & Pull out
dashboard mid panel.
19.Remove one mounting screws at glow box
location.
20.Remove one screw at front of BCM.
21. Remove four screw at glow box location and
pay out glow box
