BODY
11
10. Loosen and remove the four mounting
screws of air vent
11. Disconnect the electrical connection.
Remove music system (If applicable). (For
procedure refer music system removal process in
Electrical section).
12.Remove floor console assembly. (For
procedure refer floor console removal
process).
13.Remove PAB Assembly (If applicable). (For
procedure refer PAB removal process in SRS
section).
14. Pull out end cover LH side
15. Remove one mounting screws & Pull out
dashboard mid panel
.
16.Remove one mounting screws at glow box
location.
17.Remove one screw at front of BCM.( If
applicable )
