1.2L REVOTRON ENGINE
141
8. Lock the tensioner by using locking pin and
remove the tensioner.
SPECIAL TOOL
Pin-Timing chain tensioner plunger locking
–
5424 5890 06 04
9. Remove the movable guide rail.
10. Remove fixed guide rail.
11. Remove the timing chain from the gear train
assembly.
