1.2L REVOTRON ENGINE
147
IX. Removal of Cylinder Block Sub-
Assemblies
1. Lock the balancer shaft in the bedplate using
a locking bolt as shown below.
2. Remove the two mounting counter sunk
screw and take out the thrust washer.
3. Remove the Balancer Mass with locating pin
in balancer shaft by removing the mounting
bolt.
4. Remove the locking bolt and take out the
balancer shaft from the bedplate as indicated.
