1.2L REVOTRON ENGINE
160
7. Place the valve spring retainer.
8. Use Special Tool to compress and assemble
the valve spring lock halves.
9. Assemble the RFF along with Hydraulic Lash
Adjuster from the cylinder head as shown in
below figure.
NOTE
To avoid damage to valve tips, do not
rotate the camshaft.
10. Repeat the procedure for exhaust port, noting
the locations and components for each valve
for proper reassembly.
CAUTION
When assembling the camshaft, use care
to avoid damaging the bearing surfaces of
the cylinder head and the camshaft.
