TIAGOR

FATC

1.4. FATC CONTROL PANEL

An electronic control unit known as the control panel, which has a built in algorithm to maintain the CCM settings,

conditions set by the user, manages the climate control system automatically. The layout of the knobs and

pushbuttons on the control panel are as below.

FATC Controls

1. AC Compressor ON/OFF Button

7. AC Blower OFF Button

2. ECON (Economy Mode) Button

8. Temperature Control Knob

3. Windshield Defrost Button

9. Auto Mode

4. Rear Defogger / Demister Button

10. In-cab Sensor

5. Air Recirculation Button

11. Blower Speed Control Knob

6. Air Flow Mode Button

FATC: - FULLY AUTOMATIC TEMPERATURE

CONTROL:

GENERAL DESCRIPTION:

FATC system controls the in-cabin Temperature of

the vehicle automatically and provides maximum

passenger convenience regardless of outside

weather conditions.

! CAUTION

If the display flashes ‘ERR’ in periodic pattern (Dis-

play will show ‘ERR’ for 5 sec. and set temperature

for 30 sec.),It indicates FATC malfunctioning.

Switch over to manual mode and contact

TATA

MOTORS

authorized service station.

1. AC COMPRESSOR ON / OFF BUTTON

Press the AC compressor ON/OFF button to turn

the air conditioning ON or OFF. You will see AC

text on the display, when AC is ON.
