TIAGOR

FATC

2. ECON MODE

During ECON AC operation, the system automatically

cuts off compressor at a higher temperature than

normal AC. The operation can be used during mild

weather conditions for better fuel efficiency. Comfort

level may be compromised during this operation. By

pressing ECON button text will be displayed on

display.

3. MAX DEFROST BUTTON

a. This button directs the main airflow towards

windscreen for faster defrosting (It also overrides

any mode selection you may have made.)

b. When you turn off the button, the system returns

to its former settings

! CAUTION

For your safety make sure you have a clear view

through all the windows before driving

4. REAR WINDOW DEFOGGER/DEMISTER

This button turns the rear window demister ON or

OFF. The system automatically deactivates after 15

min of continuous operation.

5. FRESH AIR / RECIRCULATION BUTTON

A. When the recirculation Button or LED is

switched ‘ON’, air from the vehicle’s interior is

sent throughout the system.

B. When the recirculation button is switched off,

air is brought in from outside of the vehicle

(fresh mode). Whenever discomfort is felt,

switch to fresh air mode.

NOTE

1. The outside air intakes for the climate control

system are at the base of windscreen. Keep this

area clear from leaves and other debris.

2. The system should be used with recirculation

air mode for faster heat up and cool down,

however keeping the system in recirculation

mode, particularly with AC OFF, can cause the

windows fog up.

! CAUTION

It is recommended to run the vehicle in re

circulation mode to avoid clogging of air filter.

6. AIR DISTRIBUTION (MODE) BUTTON

In AUTO mode, the FATC system will regulate the

mode automatically. However, user override is

possible with the use of MODE button to select the

desired airflowmode. Each time you press theMODE

button, the display shows the mode selected.
