HEXA

GEAR BOX

3. Fit snap ring select snap ring such that it is snug

fit in the groove.

4. Slide the 5th gear subassembly along with the

needle roller cage and synchro cone such that

the synchro cone is towards engaging gear and

then slide the spacer

5. Press taper roller bearing inner race with help of

drift (Part No. 2654 5890 26 05) such that taper

is upwards.

NOTE

Ensure that the inner race of the bearing is butting

against the spacer.

6. Rotate the mains shaft assembly upside down.
