7. Diesel Pre-Heat indicator (If applicable
)
This indicator, applicable for diesel engines, comes
ON when engine starting-aid is provided by
activating glow plugs. In the Engine running
condition the indicator goes off.
8. Service/malfunction indicator:
This indicator indicates the vehicle’s engine
condition when a malfunctioning occurs in the
engine. The functioning of this lamp is as below,
Comes “ON” when key is in ‘IGN’ position and
goes ‘OFF’ when EMS performances the
system check.
Remains ‘ON’ if any fault in the EMS system.
9. Low Engine Oil Pressure Indicator:
When the ignition key is turned to the ‘IGN’
position, symbol lights up and goes off as soon as
the required engine oil pressure is developed after
starting the engine.
10. Low Fuel Indicator:
The Low Fuel warning comes on when fuel level is
low and needs fuel refilling at the earliest.
11. High Temperature Warning:
This indicator lights up when engine is hot, which
may be due to insufficient coolant in the coolant
tank or due to any other defect.
! CAUTION
RED color of temperature gauge along with telltale
indicates high coolant temp warning. This indicates
overheating that may damage the engine. This
may be due to insufficient coolant in the radiator or
due to any other defect. Take the car to the
nearest authorized Tata service station.
Never remove the radiator pressure cap from the
radiator when the engine is hot.
Do not restart the engine until the problem has
been duly attended.
