ELECTRICAL
113
8.9.2 IGNITION SWITCH WITH IMMOBILIZER
CAN VERSION PLUS KEY RING
ILLUMINATION
FUNCTION
To lock the steering wheel
To start & stop the engine
To switch on accessories and other electrical
system
LOCATION
Fitted on steering column.
REMOVAL & REFITMENT OF STEERING
LOCK CUM IGNITION SWITCH (SLCIS):
REMOVAL:
1. Disconnect battery negative terminal.
2. Remove steering nacelle. Refer “Removal &
refitment of steering nacelle" from steering
section.
3. Remove steering wheel. Refer “Removal & refitment
of steering wheel" from steering section.
4. Remove combi switch. Refer “Removal & refitment
of combi switch."
5. Disconnect steering lock cum Ignition
switch connection.
6. Unscrew Steering Lock Cum Ignition Switch
mounting screws.
7. Remove the assembly of SLCIS.
REFITMENT:
1. Refit SLCIS mtg. Screws.
2. Reconnect SLCIS connection.
3. Refit combination switch.
4. Refit steering Wheel.
5. Refit steering nacelle.
Refit battery negative terminal.
