127.
U0001-88 - Vehicle Communication Bus A- Bus off
Overview:
ISO Code
U0001-88
Customer Symptom
All warning lamps will be ON
Fault Effects (On Vehicle)
1. If vehicle in standstill; it will not crank
2. If in running condition; no gear shift allowed, Gear will
be forced to Neutral
Lamp Status (If Any)
All warnings lamps will be ON.
Fault Detection Condition
1. Short circuit between CAN_H-CAN_L, CAN_H GND,
CAN_L-Vbatt, CAN_L-GND and/or CAN_H- Vbatt
2. Open circuit of CAN_H/ CAN_L/ both lines
Normal Operating Condition
TCM ECU communicates properly with TML diagnostic Tool.
Probable Trouble Area
CAN_H and CAN_L wires
Healing Condition
1. Removal of the above mentioned shorts in the wiring
harness or at ECU pin.
2. Reconnecting CAN_H/ CAN_L/ both lines
