Preliminary Check

1. Check resistance in Diagnostic CAN pin no. 6 and 14. It should be 120 ohm.

2. Check for short conditions between CAN_H-CAN_L, CAN_H-GND, CAN_L-GND, CAN_H-Vbatt and CAN_L-

GND. There should not be any short circuit conditions.

3. Check continuity between IPC CAN_H (pin no. 15) vehicle side connector to OBD connector CAN_H (pin no. 6)

and CAN_L (pin no. 14) vehicle side connector to ODB connector (pin no.14).

Read IVN DTCs in IPC in IGN ON condition.
