AMT KIT
24
D. DC MOTOR REMOVAL AND RE-FITMENT:
Removal
Remove Oil tank (Refer oil tank removal
procedure).
Disconnect the connector of the wiring
Unscrew the three fixing screws M5x15.
INSTALLATION:
Using a screw driver, turn the joint as shown
below, to align its slot with the axis passing
through the two fixing threaded holes at 180°
below, to align it with the axe Passing
through the two fixing hole at 180°.
