49

4. Remove load floor.

5. Loosen and remove the mounting bolts from

the rear side of the seat and remove it from the

vehicle.

ASSEMBLY:

For assembly follow the reverse procedure of

removal.

III.

FRONT ROW SEAT BELT:

REMOVAL:

1. Fold the front seat to have easy access for the

belt removal.

2. Remove the lower mounting of seat belt.

3. Remove “B” pillar trim.

(For procedure refer “B”

pillar trim removal process.)

4. Remove the upper mounting bolt and the pan

head screw.

5. Remove the B pillar garnish.

6. Remove the B pillar garnish.
