HEXA

BODY

4. Loosen and remove screws of rear shoe cover

inboard RH and LH.

5. Remove two mounting bolts from the rear end

and

remove the front seat.

ASSEMBLY:

For assembly follow the reverse procedure of

removal.

II.

SECOND ROW SEAT:

NOTE:

The procedure is applicable for both seat i.e. for

the 60% and 40%.

REMOVAL

1. Pull

the

strap and tilt the back rest of the seat.

2. Pull the strap which is at the back of seat and

lift the seat towards the front side to have

access

to the mounting bolts.

3. Loosen and remove four mounting bolts and

take out the seat
