15

10.Loosen the hex. Thin nut and then take out the

split pin and disconnect the cable from hood

latch assembly.

11.Loosen and remove mounting screw and take

out the handle.

12.Remove the trim behind the bonnet release

lever.

13.Disconnect the cable from hood release lever.

14.Pull out the tree clips

(2 Nos.)

and remove the

latch cable from the lower reinforcement.

15.Pull out and remove the cable from the engine

CAUTION

Do not pull the hood latch cable from inside of cab

it can damage the rubber grommet.

FITMENT

For fitment follow the reverse procedure of

removal.
