HVAC

65

10.4.2 FRONT HVAC UNIT

DESCRIPTION

DESCRIPTION

1

ASSY HVAC UNIT W O FOOTDUCT

6

FOOT DUCT LH

2

FOOT DUCT RH

7

FLANGE FOOT DUCT LH

3

FLANGE FOOT DUCT RH

8

ASSY BLOWER COMPLETE HVAC SUBROS

4

HEATER HOSE INLET

9

SUCTION PIPE ASSY

5

HEATER HOSE HVAC OUT

10

TUBE LIQUID HVAC INLET
