SAFARI

ENGINE2.2LDICOR

Oil Separator

A step towards developing environment friendly

products, to eliminate the engine blow by being

emitted to atmosphere, the engine breather / oil

separator has been fitted. The oil separator eparates

oil from the blow by of the engine and sends it back

to engine oil sump. The remaining air, carbon particles

and other gases are sent to the inlet manifold.

There is also a spring loaded diaphragmvalve provided

on the oil separator outlet to the inlet manifold. This

prevents the flow of excessive of blow-by from the oil

separator to inlet manifold in case the air filter is

choked and high suction starts acting on outlet port

of oil separator.

No leakage past diaphragm or top cover of oil

separator is permitted. Replace the assembly if there

is any leakage.

ToAir-Intake hose

Crank case

Blow-by

gas

Oil return to crank case
