FRONT AXLE - 4
X
4
TOOLS FOR CV JOINT ASSEMBLY
(See Fig. 67)
Fig. 67
1.
Plain plier, snap ring. Pt. no. 2704 5890 3330
2.
Tang plier : snap ring Pt. no. 2704 5890 3331
3.
Clamp crimper Pt. no. 2704 5890 3332
4.
Ball assembly Pt. no. 2704 5890 3333
DISASSEMBLY AND ASSEMBLY
DISASSEMBLY RZEPPA CV JOINT
Mark the position of small end of the boot on shaft for
reassembly.
Fig. 68
Fig. 68
