TRANSFER CASE
Index Part Name
Quantity
No.
75.
Ring, Snap
1
76.
Seal Oil
1
77.
Pin, Spirol
1
78.
Adapter, Front
1
79.
Ring, Snap
1
80.
Bearing Annular
1
81.
Shaft Assembly, Input
1
82.
Bearing, Bush
1
83.
Bearing, Needle
1
84.
Shaft, Input
1
85.
Washer, Thrust
1
86.
Carrier Assembly, (Complete)
1
87.
Snap Ring
1
88.
Plate, Thrust.
1
89.
Gear, Sun
1
90.
Carrier Assembly, Planet
1
91.
Assembly Speedo Gear & Shaft
1
92.
Gear Speedo Driven
1
93.
Shaft Speedo Driven
1
94.
Seal, Speedo
1
95.
“O” Ring
1
96.
Body, Speedo
1
97.
Bolt
1
98.
Breather Assembly
1
100. Cam, Electric Shift
1
101. Spring, Torsion
1
102. Spacer
1
103. Shaft, Shift
1
105. Case Assembly, Transfer
1
106. Seal, Oil
1
Index Part Name
Quantity
No.
107. Ring Snap
1
108. Bearing, Annular
1
109. Pin, Dowel
2
111. Case, Transfer
1
112. Sealing Compound
1
113. Wire Connector, Electrical Coil
1
114. Clip Connector, Electrical Coil
1
115. ECU Module
1
116. Bracket, Relay Mounting
1
117. Connector, Three Terminal
1
118. Connector, Locking Clip
1
