TRANSFER CASE
Index Part Name
Quantity
No.
1.
Nut
1
2.
Washer
1
3.
Seal
1
4.
Rear Yoke
1
5.
Plug, Pipe
2
6.
Bolt, Hex Head
1
8.
Bolt, Hex Head
3
9.
Bracket, Sensor and Harness
1
10.
Sensor Assembly
1
13.
Motor Assembly
1
14.
Bolt, Hex Head
9
15.
Clip, Wiring Harness
1
16.
Tag Identification
1
17.
Cover Assembly Transfer Case 1
18.
Seal Oil
1
19.
Bearing Sleeve
1
20.
Nut, Hex
3
21.
Coil Assembly, Clutch
1
22.
Ring, Snap
1
23.
Bearing Annular
1
24.
Bearing, Needle
1
25.
Cover, Transfer Case
1
26.
Magnet
1
27.
Gear, Speed (8T)
1
28.
Seal, Oil
1
29.
Spring Return
1
31.
Housing, Clutch
1
33.
Lockup Assembly 2W-4W
1
34.
Ring, Snap
1
35.
Hub, Lockup
1
Index Part Name
Quantity
No.
36.
Spring, Sleeve Return
1
37.
Collar, Lockup
1
38.
Shaft, Rail
1
39.
Fork, Lockup
1
40.
Ring Snap
1
41.
Spacer
1
42.
Sprocket, Drive
1
43.
Sprocket, Driven
1
44.
Chain, Drive
1
45.
Shaft and Pump Assembly
1
49.
Clamp, hose
1
50.
Coupling Hose
1
51.
Gerotor Pump
1
54.
Facing, Lockup fork
2
55.
Assy. Shaft, Output
1
56.
Strainer, Oil
1
57.
Hub, Reduction
1
58.
Facing Reduction Fork
2
59.
Fork Assembly Reduction Shift
1
60.
Pin Roller and Retainer Assembly
1
65.
Nut
1
66.
Washer
1
67.
Seal, Oil
1
68.
Yoke Assembly DC
1
69.
Deflector Dust
1
70.
Yoke DC
1
71.
Shaft, Front Output
1
72.
Stud
5
73.
Bolt, Hex Stud.
6
74.
Adapter Assembly, Front
1
