8
TRANSFER CASE
LIST OF SPECIALTOOLS
LEVEL - I SERVICE
Sr. No.
Tool Description
Telco Part No.
1.
Repair Fixture
I
2704 5890 2807 N
2.
Yoke holder
2704 5890 2802 N
3.
Oil seal fitting tool (Motor)
2704 5890 2804 N
4.
Seal driver
2704 5890 2801 N
LEVEL - II SERVICE
Sr. No.
Tool Description
Telco Part No.
1.
Repair Fixture
II
2704 5890 2808 N
2.
Yoke holder
2704 5890 2802 N
3.
Oil seal fitting tool (Motor)
2704 5890 2804 N
4.
Seal driver
2704 5890 2801 N
5.
NRB removing fixture (input shaft)
2704 5890 2805 N
6.
Needle bearing puller (Cover)
2704 5890 2809 N
7.
Snap ring pliers (Lower output shaft)
2704 5890 2810 N
8.
Snap rings pliers (Adapter)
2704 5890 2803 N
9.
Drift for ball bearing
2704 5890 2811 N
TORQUE TABLE
Level & Drain Plug
: (20-30
ft.lb)2.8 - 4.2 kgm.
Yoke Nut Front
: (150-180
ft.lb) 20 - 25 kgm.
Case Bolts
: (20-30
ft.lb)2.8 - 4.2 kgm.
Breather Adapter
: (6-14
ft.lb)
0.8 - 1.9 kgcm.
Motor Mount
: (6-8
ft.lb)0.8 - 1.1 kgcm.
Motor Bracket
: (6-8
ft.lb)0.8 - 1.1 kgcm.
Clutch Coil Nut
: (6-8
ft.lb)0.8 - 1.1 kgcm.
Rear Output Yoke Nut
: (250-275
ft.lb) 34 - 38 kgm
