4 PL FUEL SYSTEM
Fig. 7
Fig. 6
5.
Disconnect fuel filler hose from fuel tank & filler cup.
(Fig 6.) Loosen the fuel tank mounting screws and
take out the fuel tank down.
6.
Disconnect breather hose from fuel neck. Fig 6.
7.
Disconnect underbody delivery line from filter.
(Fig 7.)
Warning :
A small amount of fuel may be released after fuel
lines are disconnected. To avoid the chance of
injury,cover the pipe to be disconnectedwith cotton
cloth. Do not use cotton waste.
Note :
To avoid damage to vapour hoses while
disconnecting, slide back the clamps then twist the lines
as you pull.
8.
Remove fuel filter from bracket.
9.
Loosen fuel pumpmounting screws.
10. Loosen fuel level gauge mounting screws.
Inspection :
1.
While removing fuel tank, check all hoses and pipes
connected to fuel tank for leaks, loose connections,
deterioration or damage.Replace if necessary.
2.
Check fuel pump and fuel level gauge gaskets for
leaks, cracks etc. Replace if necessary.
3.
Visually inspect fuel tank for leaks and damage.
Replace if necessary.
