ENGINE
140
01
ASSY.WATERPUMP
01-a SHAFT (WATERPUMP)
01-b SPACERTUBE
01-c CONICAL ROLLER BEARING
01-d OIL SEAL
01-e IMPELLER
01 -f
SLINGERWATERPUMP
01-h WATERPUMPHOUSING
01-j
AXIAL SLIDE RING
01-k GASKETWATERPUMP
01-L SHIM
01-m ASSY PACKING HOLDER
01-n HUB (WATERPUMP)
01-o CASTLE NUT
01-p SPLIT PIN
01-q WATERPUMMPBACKCOVER
01-r
GASKETWATERPUMP
01-s
COLLAR SCR
01-t
SPRINGWASHER
02
GASKET
03
COLLAR SCR
04
SPRINGWASHER
05
WATERPUMPPULLEY
06
HEX SCREW
07
LOCK PLATE
08
UPPERWATER COOLINGLINE
09
SEALINGWASHER
10
TEMP.SWITCH FOR
11
TEMPERATURETRANSDUCER
12
SEALINGWASHER
13
GASKET
14
SCREW
15
ASSY.THERMOSTATE
16
RUBBERHOSE
(UCWL TO THERMOSTAT)
17
HOSE CLAMP
18
RUBBERHOSE
(THERMOSTAT TO W.P)
19
HOSE CLMAP
20
HOSE
(THERMOSTATTO RADIATOR)
21
ASSY.ADAPTOR
(HEATER CONNECTION)
22
BANJO
23
SEALINGWASHER
24
assy. radiator & fan shroud
24a Assy.radiatorblock
24b assy fan shroud
24c
assy fan with motor
25
hex.screw
26
washer
27
hose (from radiatortopipe)
28
pipe (radiator to engine)
29
hose (radiator pipe to engine)
30
hose clamp
31
tube radiator to tank
32
tube tank to open
COOLING SYSTEM AND RADIATOR
SR.
Description
NO.
EXPLODED VIEWS
