ACCESOREIES AND BELT DRIVES (A/C AND ALTERNATOR)
20 ASSY.ACCOMPRESSOR
21 HEXSCREW
22 BRIGHTWASHER
23 SPRINGWASHER
24 POLY-VBELT
25 ASSY.BRACKET
26 SUPPORT
(ALTERNATOR BRACKET)
27 HEXFL SCREW
28 ASSY.IDLER
29 SLIDER
30 SCREW
31 NYLOCNUT
32 ASSY.SUPPORT BRACKET
33 HEXSCREW
34 BRIGHTWASHER
35 ALTERNATOR
36 HEXBOLT
37 BRIGHTWASHER
38 NYLOCNUT
39 ASSY.TENSONING
ROD -COMPLETE
40 HEXBOLT
41 SPRINGWASHER
42 HEXBOLT
SR.
Description
NO.
